WITH CONTROL LEVERS
LIFTING CAPACITY 2205 LBS
2205 LBS
124,45" inch
Fixed
181,77" inch
The electric mobile lifting crane ATLAS 1TE3L is a Full Electric crane that can reach a max lifting capacity of 2205 lbs.
The ATLAS 1TE3L is equipped with a triple electric boom that reaches a free overhang of over 118,11”.
The ATLAS 1TE3L crane is equipped with control levers that allow you to control all the movements of the lifting arm with adjustable and proportional speed to ensure maximum control during the handling and positioning of the load.
One of the key features of this Pick & Carry crane is the ability to move even with the load hanging as it does not have stabilizers.
The ATLAS 1TE3L is the smallest motorized crane in its category (only 31,50” wide) and, thanks to its extreme maneuverability, offers maximum flexibility to operate in any condition, even in limited spaces. The exceptional steering angle and the ability to rotate on itself make it perfect for working in complex environments and limited spaces.
Standard features: maintenance-free sealed AGM batteries, external battery charger, LED stack tower lights indicating correct crane operation and overload warning, emergency stop. The ATLAS 1TE3L crane also has a multifunctional display showing charge level, battery voltage and hours of operation.
Lift, lower, extend and retract the boom are electric controlled. All movements are adjustable by the operator via control levers located on the crane control panel. Speed and proportionality are managed through the movement of the levers.
Safety features:
Dynamic load limiter that prevents overloading and potential accidents. It continuously monitors the load being lifted or handled and automatically limits the operation if the load exceeds the predetermined safe limit.
A block valve is activated automatically in the event of a hydraulic hose rupture, preventing uncontrolled load descent.
The tiller handle is equipped with a speed selector that allows the speed of the vehicle to be adapted to different operating requirements. Two positions are available:
ATLAS 1TE3L can be equipped with any type of lifting accessories for specific applications: lifting suction cups, lifting beams, clamps, tilters, permanent magnets, etc.
Electric. Slow/fast speed
181,77"
Fixed
Electric with adjustable and proportional speed
2205
31,50"
124,45"
Electric with adjustable and proportional speed
Electric with adjustable and proportional speed
Cantilever cranes are often used in the aviation industry for specific aircraft-related tasks. For handling engines, dismantling seats, raising sensitive components such as radars or antennas, etc.
Counterbalance cranes are versatile and precise tools for positioning components on test benches. They offer benefits in safety, productivity and flexibility, making them a common choice for companies involved in product manufacturing and testing.
Using mini mobile cranes for tool changing and positioning on CNC machines improves the efficiency, safety and precision of machining operations. They have become essential equipment in many high-precision production workshops.
Using mini mobile cranes along assembly lines can improve production efficiency, reduce the risk of accidents, and enable loads to be handled precisely in spaces where other equipment can't be maneuvered. This helps optimize manufacturing operations.
Using mini mobile cranes to bypass ground obstacles, where traditional workshop cranes cannot access due to their stabilizing legs, offers a practical and effective solution in various scenarios. They are extremely useful tools for lifting tasks in hard-to-reach spaces.
Using counterbalance cranes to change molds is a common practice in the manufacturing industry, especially in the production of plastic parts, die-cast products and other molding processes.
All companies need to adhere to safety regulations and this means providing suitable equipment to lift heavy loads. Cranes are usually the best type of equipment for pulling and lifting items from one place to another, especially materials that need to be placed up high or in awkward areas.
We work closely with our customers to develop specific applications and customized solutions to meet the most varied needs, guaranteeing the quality standards that are a fundamental value of the Flexlifting brand.
Because every mini crane model is ready to use and requires no installation, Flexlifting mini cranes can easily be relocated from one site to another location. The machine can be transported with a truck and does not require great human power. The benefit of high return on investment makes mini cranes favorable option for many companies.
